Introduction:

Our company, Shaanxi Peter International Trade Co., Ltd. is a well-known and respected supplier in the market, with a strong track record spanning over 20 years. Our extensive experience has allowed us to establish ourselves as a trusted and reliable source for EN1092-01 Carbon Steel Plate Flanges.

We understand the importance of providing excellent service to our customers. We have built long-lasting relationships with clients by offering competitive pricing, prompt delivery, and personalized support. Our team of experts is dedicated to assisting customers throughout the entire procurement process, from product selection to after-sales service.

As a reputable supplier, we prioritize quality control and assurance. Our EN1092-01 Carbon Steel Plate Flanges undergo rigorous testing and inspection to ensure durability, precision, and compliance with relevant standards. We work closely with trusted manufacturers who share our commitment to delivering reliable and superior products.

EN1092-01 Carbon Steel Plate Flanges:

EN 1092-1 Flanges are a set of European standards that provide guidelines and specifications for flanges used in piping systems. These standards were developed by the European Committee for Standardization (CEN) to ensure the interchangeability of flanges across European countries.

EN 1092-1 Flanges cover a wide range of flange types, including welding neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. The standards specify the dimensions, material requirements, pressure ratings, and marking of flanges used in a variety of industries, including oil and gas, chemical, and water treatment.

Here are some key features and specifications of EN 1092-1 Flanges:

Materials: EN 1092-1 Flanges can be made from various materials, including carbon steel, stainless steel, and alloy steel. The material selection depends on the specific application and operating conditions.

Pressure Ratings: The flanges are designed to withstand different pressure ratings, ranging from PN2.5 to PN100. The pressure rating indicates the maximum pressure that the flange can withstand at a specific temperature.

Dimensions: EN 1092-1 Flanges are available in a range of sizes, typically from DN15 to DN6000. The dimensions of the flanges conform to ISO 7005-1 and are expressed in metric units.

Facings: The flanges have different types of facings, such as flat face (FF), raised face (RF), and ring joint (RTJ). The facing type depends on the type of gasket used and the application requirements.

Marking: EN 1092-1 Flanges are marked with the manufacturer's name or trademark, the material grade, the pressure rating, the size, and other relevant information.

EN1092-01 Carbon Steel Plate Flange Dimensions:

1.Dimensions are in millimeters(mm).

2.Dimensions can be specified by different purchasers.

Grades of Carbon Steel Flanges:

Key characteristics of steel plate flanges:

Material Composition

• Steel Types: Steel plate flanges are typically made from carbon steel, alloy steel, or stainless steel. Each type offers different properties suited to specific applications:
  • Carbon Steel: Known for its strength and affordability.
  • Alloy Steel: Offers enhanced strength, toughness, and resistance to wear.
  • Stainless Steel: Provides superior corrosion resistance and high temperature performance.

Design and Types

• Design Variants: Flanges come in several designs to match different connection needs:
  • Slip-On Flanges: Slide over the pipe and are welded both inside and outside.
  • Weld Neck Flanges: Welded to the pipe and offer high strength and good performance in high-pressure applications.
  • Blind Flanges: Used to seal the end of a pipe, preventing flow through the pipe.
  • Socket Weld Flanges: Designed for smaller diameters and used where high pressure is present.
  • Threaded Flanges: Have internal threads to connect with external pipe threads.

Pressure Rating

• Pressure Classes: Flanges are available in various pressure ratings, such as Class 150, 300, 600, and 900, to handle different pressures and service conditions.
• Specifications: The pressure rating is based on the flange’s ability to withstand internal pressure without deformation or failure.

Size and Dimensions

• Standard Sizes: Flanges come in standard sizes that match the pipe dimensions and pressure ratings. Common standards include ANSI/ASME B16.5, DIN, and EN 1092-1.
• Thickness and Diameter: The dimensions of flanges, including their thickness and diameter, vary based on the application and material specifications.

Flange Faces

• Face Types: The flange face determines how the flange will seal with the mating flange:
  • Flat Face (FF): A flat surface, suitable for low-pressure applications.
  • Raised Face (RF): Features a raised portion for a better seal under higher pressures.
  • Ring Type Joint (RTJ): Incorporates a ring joint for high-pressure and high-temperature applications.

Bolt Holes and Patterns

• Bolt Hole Size: Flanges have multiple bolt holes to secure them to other components. The size and spacing of these holes are standardized to ensure compatibility.
• Bolt Pattern: The pattern and number of bolt holes are standardized according to flange size and pressure rating.

Gasket and Sealing

• Gasket Surface: The flange surface is designed to accommodate gaskets, which provide a seal between the flanges to prevent leaks.
• Gasket Types: Various gasket materials (e.g., rubber, metal, or composite) are used depending on the application and operating conditions.

Corrosion and Environmental Resistance

• Protection Measures: Steel flanges, especially those made from carbon steel, may require coatings or galvanization to resist corrosion and environmental damage.
• Material Choices: Stainless steel flanges naturally offer better corrosion resistance compared to carbon steel.

Thermal and Mechanical Properties

• Temperature Tolerance: Steel flanges can handle a range of temperatures. Specific types, like stainless steel flanges, perform well at high temperatures.
• Mechanical Strength: Steel flanges exhibit high mechanical strength, making them suitable for high-pressure and high-stress applications.

Manufacturing and Fabrication

• Fabrication Process: Steel plate flanges are typically manufactured through processes like forging or casting, followed by machining to meet specific dimensions and tolerances.
• Quality Control: Flanges undergo various quality checks to ensure they meet industry standards and specifications.

 Installation and Maintenance

• Ease of Installation: Steel plate flanges are generally straightforward to install with standard tools and procedures.
• Maintenance Requirements: Regular inspections and maintenance are required to ensure continued integrity and performance, especially in corrosive or high-stress environments.

Features of Carbon Steel Plate Flanges:

Material Composition: Made from carbon steel, which is primarily composed of iron and carbon, offering a balance of strength and ductility.

Strength and Durability: Provides good tensile strength and durability, suitable for high-pressure and high-stress applications.

Cost-Effective: Generally less expensive than stainless steel flanges, making them a cost-effective option for many applications.

Weldability: Carbon steel is easily weldable, facilitating the installation and modification of piping systems.

Versatility: Available in various sizes and pressure ratings, making them adaptable to different industrial requirements.

Machinability: Easier to machine compared to some other metals, allowing for precise manufacturing and custom fittings.

Corrosion Resistance: Less resistant to corrosion than stainless steel; often requires coating or painting to prevent rust in corrosive environments.

Common Standards: Manufactured according to standards like ANSI/ASME B16.5, which defines dimensions, pressure ratings, and material specifications.

Applications: Widely used in industries such as oil and gas, chemical processing, water treatment, and construction for connecting pipe sections and other components.

Design Variations: Available in different types, including slip-on, weld neck, blind, and threaded, to suit various connection needs and design requirements.

Benefits of Carbon Steel Plate Flanges:

Cost-Effective: Carbon steel flanges are generally more affordable compared to stainless steel or other alloy flanges, providing a cost-effective solution for many applications.

High Strength: Carbon steel flanges offer good tensile strength and are suitable for high-pressure applications. They provide robust support and reliability in demanding conditions.

Versatility: Available in a wide range of sizes, pressure ratings, and types (such as slip-on, weld neck, blind, and threaded), making them versatile for various piping and connection needs.

Weldability: Carbon steel is easily weldable, facilitating straightforward installation and modification. This property is advantageous for custom fittings and repairs.

Machinability: Carbon steel is easier to machine compared to many other metals, allowing for precise manufacturing and customization of flanges.

Availability: Carbon steel flanges are widely produced and readily available, ensuring that you can find the specific type and size you need.

Structural Integrity: They provide reliable structural integrity and are capable of withstanding substantial mechanical loads and stresses.

Compatibility: Often used in conjunction with other carbon steel components, ensuring compatibility and consistency within a piping system.

Temperature Tolerance: Can handle a range of temperatures, making them suitable for various industrial processes and environments.

Standardization: Produced according to established standards (e.g., ANSI/ASME B16.5), which ensures consistency in dimensions, pressure ratings, and performance.

Applications of EN1092-01 Carbon Steel Plate Flanges:

EN 1092-1 is a European standard that specifies the requirements for plate flanges made from carbon steel and other materials. These flanges are used in various applications across different industries. Here’s a look at some common applications of EN 1092-1 carbon steel plate flanges:

Oil and Gas Industry

• Pipelines: Used to connect sections of pipelines that transport oil, gas, or other fluids.
• Refineries: Employed in refinery systems for transporting and processing hydrocarbons.
• Pressure Vessels: Used in flanged connections of pressure vessels for safe containment of fluids under pressure.

Petrochemical Industry

• Processing Equipment: Utilized in various processing units where chemicals are handled under high pressures and temperatures.
• Storage Tanks: Flanges are used to connect and seal storage tanks for chemicals and petrochemical products.

Power Generation

• Boiler Systems: Flanges are critical in connecting boiler components and ensuring a secure seal in high-pressure and high-temperature environments.
• Turbine and Pump Connections: Used to connect turbines and pumps in power plants, ensuring the integrity of the fluid systems.

Water Treatment and Distribution

• Water Pipelines: Employed in the connection of water pipelines for municipal water supply and treatment facilities.
• Treatment Plants: Used in water treatment plants to connect various treatment and filtration units.

HVAC Systems

• Air Handling Units: Used in HVAC systems to connect components such as ducts and air handling units.
• Piping Connections: Employed in the connection of piping systems for heating and cooling applications.

Construction and Infrastructure

• Building Services: Used in various building services applications for connecting piping systems and other infrastructure components.
• Structural Connections: Employed in structural applications where flanged connections are needed for rigidity and stability.

Marine Industry

• Shipbuilding: Utilized in shipbuilding for connecting different parts of piping systems and ensuring the integrity of fluid systems onboard ships.
• Offshore Platforms: Used in offshore oil rigs and platforms for fluid handling and pressure vessel connections.

Automotive Industry

• Cooling Systems: Used in automotive cooling systems for connecting radiators and other cooling components.
• Exhaust Systems: Employed in exhaust systems to connect various parts of the exhaust piping.
